Super Arch Fender
Arch fenders were introduced to improve upon the performance of cylindrical fenders. Arch fenders have a better Energy / Reaction force ratio and recommended for all types of applications. The very shape of these fenders helps to dissipate the stress evenly. These Compression Molded fenders are very easy to install and are maintenance free under proper installation and use conditions. Generally our Arch fenders are preferred for small to medium range Vessels. Arch Type rubber fenders are installed on docks and structures to absorb the collision energy between ship and dock during berthing. This rubber fender features low reaction force and high energy absorption. It is of reasonable structure, long service life, firm installation and easy replacement.
Dimension Table
| SUPER ARCH RUBBER FENDERS | |||||||||||||
| Fender size | L(mm) | H(mm) | A(mm) | B(mm) | W(mm) | F(mm) | D(mm) | K(mm) | E(mm) | PQ(mm) | Anchors | Weight (Kg/m) | |
| GAN | GAP | ||||||||||||
| GAN/GAP150 | 3000 | 150 | 108 | 240 | 326 | 98 | 16-20 | 50 | 500 | 2040 | M16 | 28 | 35 |
| GAN/GAP200 | 3000 | 200 | 142 | 320 | 422 | 130 | 18-25 | 50 | 500 | 2550 | M20 | 48 | 62 |
| GAN/GAP250 | 3500 | 250 | 164 | 400 | 500 | 163 | 20-30 | 62.5 | 500 | 2856 | M24 | 69 | 90 |
| GAN/GAP300 | 3500 | 300 | 194 | 480 | 595 | 195 | 25-32 | 75 | 500 | 2856 | M24 | 107 | 128 |
| GAN/GAP400 | 3500 | 400 | 266 | 640 | 808 | 260 | 25-32 | 100 | 500 | 3570 | M30 | 185 | 217 |
| GAN/GAP500 | 3500 | 500 | 318 | 800 | 981 | 325 | 25-32 | 125 | 500 | 4284 | M36 | 278 | 352 |
| GAN/GAP600 | 3000 | 600 | 373 | 960 | 1160 | 390 | 28-40 | 150 | 500 | 4896 | M42 | 411 | 488 |
| GAN/GAP800 | 3000 | 800 | 499 | 1300 | 1550 | 520 | 41-50 | 200 | 500 | 54108 | M48 | 770 | 871 |
| GAN/GAP1000 | 3000 | 1000 | 580 | 1550 | 1850 | 650 | 50-62 | 250 | 500 | 54108 | M48 | 1289 | 1390 |
Features
1. Suitable for wide range of applications
2. Simple one-piece design
3. Strong and hard wearing
4. Can be installed both vertically and horizontally
Drawing
Facility
Certifications
Case Reference
